This powerful (200 nanosecond instruction execution) yet easy-to-program (only 35 single word instructions) CMOS FLASH-based 8-bit microcontroller packs Microchip's powerful PIC® architecture into an 18-pin package and is upwards compatible with the PIC16F628, PIC16C62XA, PIC16C5X and PIC12CXXX devices.
The PIC16F628A features 4MHz internal oscillator, 128 bytes of EEPROM data memory, a capture/compare/PWM, a USART, 2 Comparators and a programmable voltage reference that make it ideal for analog/integrated level applications in automotive, industrial, appliances and consumer applications.
Vlastnosti:
- Low voltage programming
- Low speed Clock mode
- Programmable BOR
- 4MHz internal oscillator
- Programmable VREF
- 128 bytes of EEPROM
- Data Memory
- ICD
- Program Memory Type Flash
- Program Memory (KB) 3.5
- CPU Speed (MIPS) 5
- RAM Bytes 224
- Data EEPROM (bytes) 128
- Digital Communication Peripherals 1-UART, 1-A/E/USART,
- Capture/Compare/PWM Peripherals 1 CCP
- Timers 2 x 8-bit, 1 x 16-bit
- Comparators 2
- Temperature Range (C) -40 to 125
- Operating Voltage Range (V) 2 to 5.5
- Pin Count 18
Specifkace:
http://ww1.microchip.com/downloads/en/DeviceDoc/40044G.pdf
